Guidance Steering (AutoTrack) for Farming Simulator 19.
Update PL translation
Only Wopster is allowed to publish any of this code as a mod to any mod site, or file sharing site. The code is open for your own use, but give credit where due. I will not accept support for any ‘version’ of Guidance Steering that is obtained from a sketchy mod page. Versioning is controlled by me and not by any other page. This confuses people and really holds back the development which results in no fun for me!
Please be aware that this is a DEVELOPMENT VERSION!
The development version can break the game or your savegame!
The development version doesn´t support the full feature package yet!
This version should also work in Multiplayer, but keep in mind it might have bugs.
Installation / Releases
Currently the development version is only available via GitHub. When a official release version is avaiable you can download the latest version from the release section.
Please note: if there’s no release version available it means there’s no official release yet.
All official releases will be avaiable at the offical Farming Simulator ModHub.
For installing the release:
Windows: Copy the FS19_guidanceSteering_rc_.zip into your My Games\FarmingSimulator2019\mods directory.
To quickly build a zip of the developer version without the needed extra’s, use the zip.bat which is included in this repository.
Please note: the batch file requires an installed version of 7Zip or Winrar
To be able to use the GPS you first need to buy the technology for your vehicle. Either buy a new vehicle and add the GPS or drive your current vehicle to the shop and configure it there.
Toggle Guidance Steering
In order to turn guidance steering on and off hit alt + c
Open the menu
In order to open the menu hit ctrl + S.
Setting up the line
The AB mode requires two points between which the GPS is aligned.
Drive to the location where you want to setup your lines.
Hit alt + E once (or use the menu) in order to reset the AB creation.
Hit alt + E once more (or use the menu) in order to set point A.
Hit alt + E once more (or use the menu) in order to set point B which will create the track.
Hit alt + R (or use the menu) in order to detect the width of your vehicle. Unfold and lower the vehicle to get the best results.
Hit alt + plus and alt + minus in order to change the width manually. In the menu you can set the increment width in order to speed up the process.
Please note that this only works after the track creation!
In the menu you can set the offset line. If the offset is not 0 a red line will show up. Use the increment width select box (the one at the top) to set the increment and click on the button Increment offset in order to offset your line. If you set the increment to negative it will flip the offset.
Hit alt + page up and alt + page down in order to shift the track left and right. If you hold down the key the shifting of the track will speed up.
Hit alt + home in order to realign the track with the vehicle.
Terrain angle snapping
If you’re not able to create straight lines yourself you can enable angle snapping in the menu. This will align the AB lines with the terrain.
Toggle guidance steering
Once a track is created hit alt + X to toggle the steering.
Currently the automatic steering stops at the headland when cruise control is enabled. Headland turning is still being worked on.
Store and load tracks
It’s also possible to store the tracks and reload them. Open the second page in the menu in order to do it.
On the vanilla John Deere vehicles the starfires visibility is toggled when you choose to buy the GPS system. If you want the same effect on your mod
Copyright (c) 2019 Wopster. All rights reserved.
Special thanks to workflowsen for creating the icon!
